BELL Lighting 60456 16W 4 Pin 2D LED Replacement Lamp for 28W 3000K

BELL Lighting 60456 16W 4 Pin 2D LED Replacement Lamp for 28W 3000K

GR10q 4 pin cap

The LED Square 4 Pin Lamps give the user the familiarity of the renowned CFL Square Lamps combined with the energy saving benefits of LED lighting. With a 3 year warranty, these 16W CFL replacements will stand the test of time.

• Replacement for 28W CFL 2D Square lamps
• Same aesthetic as CFL 2D Square lamp but reduced energy consumption
• Retrofit
• lumens 1800lm
• 25000 Hours
• Perfect for commercial & domestic applications
• Quick, easy installation
• Not Dimmable
• 211mm Width 24mm Depth

It is recommended that the installation of this product be carried out by a qualified electrician. Isolate mains supply before commencing

Magnetic Ballast

Remove the starter and any power factor capacitor and plug the LED 2D retrofit lamp directly into the socket.

Electronic Ballast

The LED 2D Retrofit lamp does not require any ballast. Bypass the ballast by rewiring the luminaire following the wiring on the box.

The lamp holder needs to be rewired with the LIVE to one side and the NEUTRAL to the other.
