Philips 9290008634 Xitanium 75W 0.7-2A 54V 230V

Philips 9290008634 Xitanium 75W 0.7-2A 54V 230V

Xitanium LED drivers are designed to operate LED solutions for general lighting applications such as linear lighting, as well as downlighting and spot/accent lighting. High reliability underpinned by 5-year warranty, enhanced by specific features that protect the connected LED module, e.g. hot wiring, reduced ripple current and thermal derating. Most drivers feature central DC operation. In the coming years LEDs will continue to increase in efficiency, creating generation and complexity challenges for OEMs. With Xitanium LED drivers, flexibility in luminaire design is assured thanks to an adjustable output current. Application-oriented operating windows offer the flexibility required to provide the stable lumen output and light quality levels that lighting specifiers and architects demand. And the adjustable output current also enables operation of various LED PCB solutions from different manufacturers.

• Line Frequency 50 to 60 Hz

• Input Frequency 50 to 60 Hz

• Mains voltage operation (DC) 168-275 V

• Total Harmonic Distortion IEC (Max) 20 %

• Power Consumption 75 W
• Output Current Ripple (Max) 4 %

• Maximum Efficiency at Full Load 88 %

• Output Current (Max) 2000 mA

• Output Current (Nom) 1350 mA

• Output Current Tolerance (Max) 5 %

• Mains voltage performance (DC) 186-250 V

• Earth Leakage Current (Max) 0.3 mA

• Open Circuit Voltage (DC) (Max) 60 V

• Input Current (Nom) 420 mA

• Inrush Current Peak (Max) 21 A
• Output Power (Max) 75 W

• Output Power (Nom) 48 W

• Default output current 700-2000 mA
• Dimensions 420mm L 30mm W 26mm H

Philips 9290008634
