Philips 929000950606 Xitanium 36W 0.12-0.4A 115V 230V

Philips 929000950606 Xitanium 36W 0.12-0.4A 115V 230V

9290009506 Electrical Data

• Line Frequency 50 to 60 Hz
• Input Frequency 50 to 60 Hz
• Mains voltage operation (DC) 168-275 V
• Total Harmonic Distortion IEC (Max) 20 %
• Output Current Ripple (Max) 4 %
• Maximum Efficiency at Full Load 91.4 %
• Output Current (Max) 400 mA
• Output Current Tolerance (Max) 5 %
• Mains voltage performance (DC) 186-250 V
• Power Factor (Fraction) 0.9
• Open Circuit Voltage (DC) (Max) 330 V
• Protection Level Up (L-N) at 5 kA (Max) 1 kV
• Protection Level Up (LN-Earth) at 5 kA (Max) 2 kV
• Input current (AC) 0.17 mA
• Input current (DC) 0.19
• Inrush Current Peak (Max) 14 A
• Output Power (Max) 36 W
• Default output current 120 mA
• Inrush Current Width to 50% of Peak 250 μs
• Power Factor 100% Load (Max) 0.9
• Energy Metering No
• Output Power (Min) 10 W
• Output Current (Min) 120 mA
• Output Voltage (Max) 115 V
• Output Voltage (Min) 50 V

Philips 9290009506
