Philips 9290009642 Xi LP 7OW 0.2-0.7A SL 230V C150 sXt

Philips 9290009642 Xi LP 7OW 0.2-0.7A SL 230V C150 sXt

Also Code 929000964006

Xitanium LITE Prog LED Xtreme drivers
Philips Xitanium Lite Programmable LED drivers are value engineered to deliver a carefully selected feature set and high-end performance, making it a preferred choice for many outdoor applications. The portfolio offers high flexibility with a customizable operating window, enabling differentiation in LED lighting designs via system tuning and being
prepared for LED efficacy upgrades.

• Rated input voltage range 220 ... 240 Vac Performance
• Input voltage range 198 ... 264 Vac Operational
• Rated input frequency range 50 ... 60 Hz Performance
• Input frequency range 45 ... 66 Hz Operational
• Regulation method Constant Current
• Output voltage 50 ... 150 Vdc See graph, Wattage 4-70W
• Output voltage max. 170 V Peak voltage at open load
• Programmable output current 200 ... 700 mA
• Control method LineSwitch, Dynadimmer LITE
• Dimming range 10 ...100 % Output current amplitude dimming

Philips 9290009642
