Tridonic 28002054 LCI 150W 325–1050mA 300V o4a sl PRE mod (INDUSTRY)

Tridonic 28002054 LCI 150W 325–1050mA 300V o4a sl PRE mod (INDUSTRY)

Product description

• NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
• Constant current built-in LED driver, particularly suitable for industrial applications in tough environments with elevated ambient temperatures such as cold warehouses or factories
• Dimming range 1 to 100 %
• Adjustable output current between 325 and 1,050 mA
• Max. output power 150 W
• Suitable for mains voltage peaks (burst/surge) up to 4 kV
• Expanded temperature range of -25 ... +50 °C
• Nominal lifetime up to 100,000 h (at ta 50 °C)
• 5 years guarantee

Housing properties

• White slim metal casing
• Type of protection IP20

Interfaces

• one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION V2)
• ready2mains (configuration and dimming via mains)
• Terminal blocks: 0° push terminals

Functions

• Adjustable output current in 1-mA-steps (I-SELECT resistor or eD)
• Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance)
• Constant light output function (CLO)
• Power-up fading at AC
• Intelligent Temperature Guard (overtemperature protection)
• Intelligent Voltage Guard (overvoltage and undervoltage monitoring)
• Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
• Suitable for emergency escape lighting systems acc. to EN 50172

Benefits

• Application-oriented operating window for maximum compatibility
• Best energy savings due to low stand-by losses
• Flexible configuration via DALI, ready2mains and I-SELECT 2
• Extended vibration damping
• Increased safety through robust design and advanced testing under extreme test conditions
• High reliability through the selection of exclusive components
