Tridonic 87500753 LC 25/700/36 fixC SR SNC2

Tridonic 87500753 LC 25/700/36 fixC SR SNC2

Product description

• Independent driver with strain-relief housing
• Temperature protection as per EN 61347-2-13 C5e
• Output current 700 mA
• Forward Voltage 22-36V
• Output power 16.1 - 25 W
• Nominal lifetime up to 50,000 h
• 5 years guarantee

Housing properties

• Casing: polycarbonate, white
• Type of protection IP20
• Push-in terminals
• 2 separate strain relief parts for input and output cables with highly robust clamps

Functions

• Overload protection
• Short-circuit protection
• No-load protection
• No output current overshoot at mains on/off
• Burst protection voltage 1 kV
• Surge protection voltage 1 kV (L to N)
• Surge protection voltage 2 kV (L/N to earth)
