Tridonic 87500909 LC 25/350-600/42 o4a T-W EXC3
Tridonic 87500909 LC 25/350-600/42 o4a T-W EXC3
Regular price
£30.00 GBP + VAT
Regular price
Sale price
£30.00 GBP
Shipping calculated at checkout.
Tridonic 87500909 LC 25/350-600/42 o4a T-W EXC3
- Dimmable constant current / in-track LED driver
- Optional accessory ACU ALU NIPPLE M10x1 for mounting the luminaire head
- Compatible with Global Trac PULSE from Nordic Aluminum and OneTrack from Stucchi, see data sheet chapter 3.8
- Dimming range 1 to 100 % (min. 3.5 mA)
- For luminaires of protection class II
- Temperature protection as per EN 61347-2-13 C5e
- Adjustable output current between 350 and 600 mA via I-SELECT 2 plugs or DAL
- Forward Voltge 14-42V
- Max. output power 25 W
- Up to 83 % efficiency
- Power input on stand-by < 0.5 W
- Nominal lifetime up to 100,000 h
Housing properties
- Casing: polycarbonate, white
- Type of protection IP20
Interfaces
- one4all (DALI-2, switchDIM, corridorFUNCTION)
- Terminal blocks: 45° push terminals
Functions
- Adjustable output current in 1-mA-steps (DALI-2, I-SELECT 2)
- Overtemperature protection
- Overload protection
- Short-circuit protection
- No-load protection
- Burst protection voltage 2 kV
- Surge protection voltage 1 kV (L to N)
Product features
Product features
Energy Saving, Compact Design
